Unifi 10 porta 10 GbE PoE switch - USW-Pro-XG-10-PoE-EU

Lýsing High-Speed Connectivity The Ubiquiti UniFi Switch Pro XG 10 PoE (USW-Pro-XG-10-PoE) is a professional-grade Layer 3 switch designed to meet the demands of modern networks. It features ten 10 Gigabit Ethernet (GbE) PoE ports and two 10G SFP ports, providing a total non-blocking throughput of 120 Gbps and a switching capacity of 240 Gbps. This robust configuration ensures rapid data transfer rates, accommodating bandwidth-intensive applications such as high-definition video streaming, online gaming, and large file transfers. Dimensions 442.4 x 285 x 44 mm (17.4 x 11.2 x 1.7″) Port Layout 10 GbE RJ45 10 (All PoE ) (10G/5G/2.5G/1G/100M) 10G SFP 2 (10G/1G) Max. PoE Output Up to PoE Total PoE Availability 400W Redundancy DC Power Backup Layer 3 ✓ Form Factor Rack mount (1U) Etherlighting™ ✓ Performance Switching Capacity 240 Gbps Total Non-Blocking Throughput 120 Gbps Forwarding Rate 179 Mpps Supported VLANs 1,000 MAC Address Table Size 32,000 L3 Table Size ARP Entries 12,000 IPv4 Routes 12,000 Packet Buffer Size 2 MB Layer 3 Features DHCP Server (Local Networks) ✓ DHCP Relay ✓ Inter-VLAN Routing (Local Networks) ✓ Static Routing (Local Networks) ✓ Layer 2 Features LACP Port Aggregation ✓ STP & RSTP ✓ QoS (DSCP) ✓ Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron) ✓ Advanced IGMP Configuration (Querier, Fast Leave, Router Port) ✓ IGMP Snooping ✓ 802.1X Control ✓ MAC-Based ACLs & Device Isolation ✓ DHCP Snooping & Guarding ✓ Egress Rate Limit ✓ Flow Control ✓ Storm Control ✓ Multicast & Broadcast Rate Limiting ✓ MAC Address Blocking ✓ IP-Based ACLs & Network Isolation ✓ MAC-Based Port Restriction ✓ Port Isolation ✓ Port Mirroring ✓ Jumbo Frames ✓ LLDP-MED ✓ Voice VLAN ✓ Loop Protection ✓ Hardware PoE Ports PoE 10 Max. PoE Wattage per Port by PSE PoE 15.4W PoE 30W PoE 60W PoE 90W Max. Power Consumption 65W (Excluding PoE output) 520W (Including PoE output) Power Method (1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input Power Input Method AC input Power Supply AC/DC, internal, 550W Supported Voltage Range 100—240V AC Management Ethernet AR Weight Without mounting brackets: 4.6 kg (10.14 lb) With mounting brackets: 4.7 kg (10.36 lb) Enclosure Material SGCC steel Mount Material SGCC steel LCM Display 1.3″ touchscreen ESD/EMP Protection Air: ± 30kV, contact: ± 30kV Ambient Operating Temperature -5 to 40° C (23 to 104° F) Ambient Operating Humidity 10 to 90% noncondensing Etherlighting™ Ethernet ✓ SFP ✓ LEDs RPS ✓ System ✓ Certifications CE, FCC, IC NDAA Compliant ✓
